Honour Optics grows Nd, Er, Cr, Tm, Yb, Ho and no doped YAG crystals using the Czochralski technique.

Capabilities：

1. Nd dopant concentration between 0.6 at%～1.2 at%;

2. Rod sizes from 2mm to 16.5mm in diameter and from 1mm to 180mm in length;

3. Large rod and slab dimensions and non-standard dopant concentrations are available upon request;

4. AR, HR and HT coating are available upon request.

Specification:

Dopant Concentration Tolerance---------------------0.1%

Parallelism --------------------------------------------<10 arc seconds

Perpendicularity --------------------------------------<5 arc minutes

Chamfer------------------------------------------------0.1mm @45°

Clear Aperture-----------------------------------------95%

Surface Quality----------------------------------------10/5

Surface Flatness---------------------------------------λ/10 @ 633nm

Wavefront Distortion---------------------------------<7mm diameter: λ/10@633nm

                                                                                  ≥7mm diameter: λ/8@633nm

Damage Threshold-----------------------------------over 15J/CM2 TEM00, 10NS, 10HZ
