Beta-Barium Borate (β-BaB2O4 or BBO) is a kind of nonlinear crystal with good performance. It can be widely used in dye laser, ultrafast pulse laser, titanium sapphire, argon ion laser, copper vapor laser and other different types of laser systems. In addition, the OPO and OPA systems of BBO crystal can be used to generate a large range of adjustable phase dry light radiation from ultraviolet to infrared.

Specifications:

Dimension Tolerance----------------(W±0.1mm)x(H±0.1mm)x(L+0.5/-0.1mm)

Angle Tolerance----------------------△θ< 0.25°,△Φ < 0.25°

Clear Aperture-----------------------central 95% of the diameter

Surface Flatness--------------------<λ/10 at 633nm

Wavefront Distortion---------------<λ/8 @ 633nm

Chamfer--------------------------------0.1mm@45°

Surface Quality (S/D)---------------10 /5

Parallelism----------------------------< 20 arc seconds

Perpendicularity---------------------< 5 arc minutes

Coatings: Protective (P) and Anti-reflection (AR) coating available upon customer’s requests

Damage threshold------------------>1 GW/cmfor1064nm,TEM00,10ns,10HZ(polished only)

                              ------------------>0.5 GW/cm2for 1064nm,TEM00,10ns,10HZ(AR-coated)

                              ------------------>0.3 GW/cm2 for 532nm,TEM00,10ns,10HZ(AR-coatd)
